The perfect gravel hub.

The New SPANK HEX DRIVE HUB, featuring:

• Oversized bearings for optimal adaptability
• Simple to maintain
• Lightweight
• Advanced seal system

CLASSIFICATION & INTENDED USE

ALL MOUNTAIN	TRAIL	ENDURO	FREERIDE	DOWNHILL	GRAVEL	XC
					✔	✔



Highly weight-optimized front hub, ideal for Gravel and XC.

Ø28 bearings minimize overall weight, and allow adaptability up to 15mm thru axles

Unique flange design reduces dish requirement and minimizes tension range between drive side and non-drive side spokes

Compatible with Ø28 HEX front hub adapters only

Advanced seal system improves prevention of bearing contamination



SPECIFICATIONS

HOLE COUNT:	28H J-Hook
DISC MOUNT:	6-bolt
MATERIAL:	CNC optimized forged alloy hub body
FINISH:	Matte anodized, laser logos

F12/15

CONFIGURATION:	12x100, J-hook
WEIGHT +/- (g):	147
ADAPTORS INCLUDED:	Ø28 QRx100
ADAPTORS AVAILABLE SEPARATELY:	Ø28 15x100

ADAPTERS COMPATIBLE WITH SPANK HEX GRAVEL FRONT HUBS

F12/15	HEX Ø28 Front Hub 15x100/110 Adapter





SERVICE KITS COMPATIBLE WITH SPANK HEX GRAVEL FRONT HUBS

HEX Ø28 Front Hub Replacement Bearing Kit
