Leading-edge NEW OEM IHI Turbocharger Clip for Hose CN976562

BRAND NEW GENUINE MITSUBISHI TURBOCHARGER

This is a BRAND NEW GENUINE MITSUBISHI TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 49177-03190
Interchangeable Number: 4917703190, 49177-03193, 4917703193, 49177-03200, 4917703200
OEM Number: 1G777-17012, 1G77717012, 1G777-17014, 1G77717014, 1J751-17011, 1J75117011, 1J752-17012, 1J75217012
Turbo Model: TD04L4, TD04L4-09TK3-5.0
Manufacturer: Mitsubishi Heavy Industries - MHI

Engine: V3307-DI-TE3-Q, V3307-DI-T-E3B, Stage 3B (Tier 4), V3307-DI-T-E3BB
Displacement: 3.3L, 3769 ccm, 4 Cylinders Inline
Fuel: Diesel, Naturally Aspirated
Power: 73/85 kW, 114 HP
Speed: 3000 RPM

Actuator Pressure (P1): 81.3 +/- 2.7 kPa, 610 +/- 20 mmHg, 11.76 +/- 0.39 PSI
Actuator Pressure (P2): 148.0 kPa, 1110 mmHg, 21.47 PSI
Actuator: 49477-18701
Bearing Housing: 49177-20110
CHRA: 49177-08471
Compressor Housing: 49377-58180/49377-58110
Cooling: Air
Repair Kit: 49177-80000
Turbine Housing: 49377-13960

NOTE: Wastegated.

Application:
Kubota Industrial with V3307-DI-T-E3BB Engine
Kubota Industrial, Tractor, Various, Earth Moving with V3307-DI-TE3-Q Engine
Kubota M6040, M7040, SVL75, SVL90 Compact Track Loader

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
